Hvac Duct Mounted Smoke Detector

The duct smoke detector is fitted to the side the top or the bottom of the ventilation duct and has two tubes which extend into the air duct through holes in the duct wall.

Hvac duct mounted smoke detector.

The duct smoke detectors are constructed of a black high impact polymer with a clear plastic cover and attach directly to the hvac system duct. One unit can accommodate multiple installation footprints to overcome mounting constraints. A duct smoke detector should shut off a typical blower and fresh air and turn on the exhaust. Duct smoke detection equipment a duct smoke detector is a device or group of devices used to detect the presence of smoke in the airstream of ductwork sections of the hvac air handling systems typically used in commercial buildings.

Smoke heat and duct detectors model description e pd photoelectric smoke detector. Typical smoke detection devices used for duct application include smoke detector sensors within a housing mounted. Both also have exceptions that allow the deletion of the return duct smoke detectors if the area served is supplied with area smoke detectors and they are configured to control the hvac system in the same way that the duct detectors would have. The duct smoke detector should be compatible with building automation and fire alarm systems.

The duct smoke detector samples air for early detection of smoke and products of combustion present in air moving through hvac ducts. Duct detectors aren t a replacement for room sensors. Duct smoke detectors are a key component of fire detection and fire alarm systems. Therefore they should complement the buildings fire detection system and not serve as the primary fire detection system.

Hvac duct smoke detection. Nor should it serve as an early warning detection system. The table below lists the available detector models. Tool free plug in sampling tubes speed and simplify installation.

Innovairflex duct smoke detectors combine an impressive collection of innovations to greatly simplify hvac system monitoring. If the duct system is designed to carry more than 2000 cfm 5 tons nominal of air you need one in the return if imc is being followed and the supply if nfpa is being followed. Furthermore intentions for using duct smoke detectors should not be a substitute for area smoke detectors. It is preferred that the occupied and non occupied areas and spaces have smoke detectors simply because the fans in air handlers or that move air through duct work may not be operational at all times so having smoke detectors in the duct work will not offer the amount of protection that smoke detectors would offer in the spaces or area served whether those areas or spaces are occupied or not.

Nfpa 72 also states that a duct smoke detector is not allowed to replace an area smoke detector.
